600x600mm Square Composite Manhole Cover
Our FRP Manhole Covers has the characteristics of safety, corrosion resistance and easy installation. Specially produced for gas stations, with guaranteed quality!
Product information
Name |
Light weight composite manhole covers |
Material: |
Composit(SMC) |
Size: |
Clear opening 600x600mm (23.6") |
Weight: |
43kgs/95lbs |
Load: |
D400 |
Standard: |
EN124-5 |
With Central Dip Port
Standard Features
●Standard:EN124-5
●Clear opening: 600x600mm to D400/C250/B125/A15
●Material:
Composite Firbreglass and special resin that is moulded at high temperature and high pressure. Composite Sheet Moulding Compound( SMC).
●Watertight Seal
Integrated cover creats a watertight seal between the cover and frame to make sure the good watertight function.
●Anti-Slip surface
M&C’s Cover’s top surface material has a better slip-resistance value in a wet , dry or worn state to increase safety.
●Lockable
Our composite manhole covers are locking with three stainless stell bolts which not only improves site and location security and provides security against theft and malicious damage.
●Double lifting hole
600mm serices composite FRP manhole covers have two ways of lifting handle hole to chose . Two lifting handles or One are all available.
●Customized available
M&C have professional engineering department and our composite drain covers can be personalised with your company name , services phone number or design or other required information .Our covers can also be produced in a range of colours.
Specification
Unit : MM
ltem No. |
Dimensions |
Load Rating |
Weight |
||||||
A | B | C | H |
Cover Weight |
Total Weight |
||||
MC-600x600D |
600 | 750 | 646 |
70 |
400KN/D400 |
31Kg/68lbs |
36Kg/79.5Ibs |
||
MC-600x600C |
600 | 750 | 646 |
70 |
250KN/C250 |
24Kg/53lbs |
29Kg/64lbs |
||
MC-600x600B | 600 | 750 | 646 | 70 | 125KN/B125 | 20kg/44lbs | 26kg/57lbs | ||
MC-600x600A | 600 | 750 | 646 | 70 | 15KN/A15 | 13kg/28.6lbs | 19kg/42lbs |
